一、YA40Y帶散熱器彈簧全啟式安全閥概述：
YA40Y帶散熱器彈簧全啟式安全閥適用于工作溫度≤450℃的空氣、水、氮氫混合氣等介質的設備或管路上，YA40Y-P適用于工作溫度≤300℃有腐蝕性介質的設備或管路上，作為超壓保護裝置。
二、主要零部件材料：
|
NO. |
零件名稱 |
YA40Y-C材料 |
YA40Y-P材料 |
YA40Y-I材料 |
|
1 |
閥體 |
WCB |
ZG1Cr18Ni9Ti |
ZG1Cr5Mo |
|
2 |
閥座 |
2Cr13 |
1Cr18Ni9Ti |
1Cr18Ni9Ti |
|
3 |
調節圈 |
2Cr13 |
1Cr18Ni9Ti |
1Cr18Ni9Ti |
|
4 |
閥瓣 |
2Cr13 |
1Cr18Ni9Ti |
1Cr18Ni9Ti |
|
5 |
導向套 |
2Cr13 |
1Cr18Ni9Ti |
1Cr18Ni9Ti |
|
6 |
散熱器 |
ZG230-450 |
ZG230-450 |
ZG230-450 |
|
7 |
閥蓋 |
ZG230-450 |
ZG230-450 |
ZG230-450 |
|
8 |
彈簧 |
50CrVA |
50CrVA包覆氟塑料 |
50CrVA包覆氟塑料 |
|
9 |
閥桿 |
2Cr13 |
1Cr18Ni9Ti |
2Cr13 |
|
10 |
調整螺桿 |
45 |
1Cr18Ni9Ti |
2Cr13 |
|
11 |
閥帽 |
ZG200-400 |
ZG200-400 |
ZG200-400 |
|
|
密封面材料 |
堆焊Co基硬質合金 |
||
三、外形尺寸和連接尺寸：
|
型號 |
公稱通徑 |
do |
D |
K |
g |
g1 |
b |
f |
f1 |
Z-ød |
DN |
D1 |
K1 |
g3 |
g2 |
b1 |
f |
f1 |
z1-ød1 |
L |
L1 |
≈H |
|
YA40Y-16C |
20 |
15 |
105 |
75 |
|
55 |
16 |
2 |
|
4-14 |
25 |
115 |
85 |
|
65 |
16 |
2 |
|
4-14 |
110 |
95 |
518 |
|
25 |
16 |
115 |
85 |
|
65 |
16 |
2 |
|
4-14 |
32 |
140 |
100 |
|
78 |
18 |
2 |
|
4-18 |
110 |
95 |
518 |
|
|
32 |
20 |
140 |
100 |
|
78 |
18 |
2 |
|
4-18 |
40 |
150 |
110 |
|
85 |
18 |
3 |
|
4-18 |
115 |
100 |
518 |
|
|
40 |
25 |
150 |
110 |
|
85 |
18 |
3 |
|
4-18 |
50 |
165 |
125 |
|
100 |
20 |
3 |
|
4-18 |
120 |
110 |
579 |
|
|
50 |
32 |
165 |
125 |
|
100 |
20 |
3 |
|
4-18 |
65 |
185 |
145 |
|
120 |
20 |
3 |
|
4-18 |
135 |
120 |
639 |
|
|
65 |
40 |
185 |
145 |
|
120 |
20 |
3 |
|
4-18 |
80 |
200 |
160 |
|
135 |
20 |
3 |
|
8-18 |
160 |
140 |
671 |
|
|
80 |
50 |
200 |
160 |
|
135 |
20 |
3 |
|
8-18 |
100 |
220 |
180 |
|
155 |
22 |
3 |
|
8-18 |
170 |
135 |
676 |
|
|
100 |
65 |
220 |
180 |
|
155 |
22 |
3 |
|
8-18 |
125 |
250 |
210 |
|
185 |
22 |
3 |
|
8-18 |
195 |
175 |
787 |
|
|
125 |
80 |
250 |
210 |
|
185 |
22 |
3 |
|
8-18 |
150 |
285 |
240 |
|
210 |
24 |
3 |
|
8-23 |
210 |
190 |
977 |
|
|
150 |
100 |
285 |
240 |
|
210 |
24 |
3 |
|
8-23 |
175 |
310 |
270 |
|
240 |
26 |
3 |
|
8-23 |
255 |
230 |
1035 |
|
|
200 |
125 |
340 |
295 |
|
265 |
26 |
3 |
|
12-23 |
250 |
405 |
355 |
|
320 |
30 |
3 |
|
12-26 |
300 |
260 |
1193 |
|
|
YA40Y-25 |
20 |
15 |
105 |
75 |
|
55 |
16 |
2 |
|
4-14 |
25 |
115 |
85 |
|
65 |
16 |
2 |
|
4-14 |
110 |
95 |
518 |
|
25 |
16 |
115 |
85 |
|
65 |
16 |
2 |
|
4-14 |
32 |
140 |
100 |
|
78 |
18 |
2 |
|
4-18 |
110 |
95 |
518 |
|
|
32 |
20 |
140 |
100 |
|
78 |
18 |
2 |
|
4-18 |
40 |
150 |
110 |
|
85 |
18 |
3 |
|
4-18 |
115 |
100 |
518 |
|
|
40 |
25 |
150 |
110 |
|
85 |
18 |
3 |
|
4-18 |
50 |
165 |
125 |
|
100 |
20 |
3 |
|
4-18 |
120 |
110 |
579 |
|
|
50 |
32 |
165 |
125 |
|
100 |
20 |
3 |
|
4-18 |
65 |
185 |
145 |
|
120 |
20 |
3 |
|
4-18 |
135 |
120 |
639 |
|
|
65 |
40 |
185 |
145 |
|
120 |
22 |
3 |
|
8-18 |
80 |
200 |
160 |
|
135 |
20 |
3 |
|
8-18 |
160 |
140 |
671 |
|
|
80 |
50 |
200 |
160 |
|
135 |
22 |
3 |
|
8-18 |
100 |
220 |
180 |
|
155 |
22 |
3 |
|
8-18 |
170 |
135 |
676 |
|
|
100 |
65 |
230 |
190 |
|
160 |
24 |
3 |
|
8-23 |
125 |
250 |
210 |
|
185 |
22 |
3 |
|
8-18 |
195 |
175 |
787 |
|
|
125 |
80 |
270 |
220 |
|
188 |
28 |
3 |
|
8-26 |
150 |
285 |
240 |
|
210 |
24 |
3 |
|
8-23 |
210 |
190 |
977 |
|
|
150 |
100 |
300 |
250 |
|
218 |
30 |
3 |
|
8-26 |
175 |
310 |
270 |
|
240 |
26 |
3 |
|
8-23 |
255 |
230 |
1035 |
|
|
200 |
125 |
360 |
310 |
|
278 |
34 |
3 |
|
12-26 |
250 |
405 |
355 |
|
320 |
30 |
3 |
|
12-26 |
300 |
260 |
1193 |
